> Pickup Truck Crane
Pickup Crane EC10WH01
- Rated capacity: 2,000 lb / 1 ton
- Lifting range: 0-1,680 mm
- Arm length range 930-1,230 mm
- Product description: Pickup truck crane with hand winch EC10WH01 rated capacity 1 ton max. strength 125% lifting range 0-1,680 mm arm length range 930-1,230 mm
Product introduction
| Model | EC05WH01 | EC10WH01 |
| Rated capacity | 1,000 lb / 0.5 ton | 2,000 lb / 1 ton |
| Max. strength | 125% | 125% |
| Lifting range | 90 - 1,540 mm | 0 - 1,680 mm |
| Arm length range | 800 - 1,100 mm | 930 - 1,230 mm |
| Hydraulic pump | single 1 ton | single 3 ton |
| Ram stroke | 490 mm | 380 mm |
| Hand winch | with | with |
| Feature | 360 degree swivel, high profile with steel rope and chain | 360 degree swivel, high profile with steel rope and chain |
| N.W. | 49 kg | 52.5 kg |
