> Transmission Jack - Vertical
Transmission Jack TJ05VH01T
- Capacity: 0.5 ton
- Min. height: 830 mm
- Max. height: 1815 mm
- Stage: 2
- Product description: Hydraulic transmission jack - vertical type capacity 0.5 ton with 2 stages min. height 830 mm max. height 1815 mm
Product introduction
| Model | TJ05VH01T |
| Capacity | 0.5 ton |
| Max. strength | 150% |
| Min. height | 830 mm |
| Max. height | 1,815 mm |
| Hydraulic pump | doubl cylinder |
| 1st stage stroke | 470 mm |
| 2nd stage stroke | 460 mm |
| Saddle | AT10T12 |
| Caster | 3.5" steel swivel |
| Feature | with pedal and handle |
| N.W. | 84 kg |
