> Hand Crank & Lever Winch
Hand Lever Winch HWL200
- Rated capacity: 2,000 kg
- Speed ratio: 22.68 : 1
- Travel per act: 350 mm
- Hub dia. x width: Φ90 mm x 195 mm
- Product description: Multi-functional hand lever winch - without/with cable - HWL200 Steel painted. Features double friction discs, new braking pawl and change over ratchet mechanism. Widely used to lift, pull and stre
Product introduction
| Model | HWL200 | HWL200A |
| Rated capacity | 2,000 kg | 2,000 kg |
| Test load | 24.5 kN |
24.5 kN |
| Speed ratio | 22.68 : 1 |
22.68 : 1 |
| Travel per act |
350 mm max. |
350 mm max. |
| Hand force | 130 N min. |
130 N min. |
| Hub diameter and width |
Φ90 mm x 195 mm |
Φ90 mm x 195 mm |
| Mounted cable | without |
Φ9 mm x 10 M with hook |
| Packing size | 46 x 32 x 30 mm / 1-pc |
46 x 32 x 30 mm / 1-pc |
| N.W. | 25.1 kg | 29.35 kg |
