> Hand Crank & Lever Winch
Hand Lever Winch HWL100
- Rated capacity: 1,000 kg
- Speed ratio: 12.19 : 1
- Travel per act: 350 mm
- Hub dia. x width: Φ76 mm x 154 mm
- Product description: Multi-functional hand lever winch - without/with cable - HWL100 Steel painted. Features double friction discs, new braking pawl and change over ratchet mechanism. Widely used to lift, pull and stre
Product introduction
| Model | HWL100 | HWL100A |
| Rated capacity | 1,000 kg | 1,000 kg |
| Test load | 12.25 kN | 12.25 kN |
| Speed ratio | 12.19 : 1 | 12.19 : 1 |
| Travel per act |
350 mm max. |
350 mm max. |
| Hand force | 120 N min. | 120 N min. |
| Hub diameter and width |
Φ76 mm x 154 mm |
Φ76 mm x 154 mm |
| Mounted cable | without |
Φ8 mm x 10 M with hook |
| Packing size | 39 x 28 x 26 mm / 1-pc | 120 x 100 x 118 cm / 40-pc |
| N.W. | 19.7 kg | 23.03 kg |
PREVIOUS：Hand Lever Winch HWL050
NEXT：Hand Lever Winch HWL200
